368501-1
Manufacturer:
TE Connectivity
Mfr.Part #:
368501-1
Datasheet:
Description:
Headers and Wire Housings Cable, Free Hanging Plug, Socket Number of Positions:4 Pitch:3.5 mm
| Parameter | Value |
|---|---|
| Length | 17.399 mm |
| Width | 15.9 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -30 °C |
| Height | 21.59 mm |
| Packaging | Bulk |
| Depth | 21.6 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Pitch | 3.5 mm |
| Current Rating | 14 A |
| Orientation | Straight |
| Lifecycle Status | Production (Last Updated: 2 weeks ago) |
| Color | Natural |
| Gender | Female |
| Number of Contacts | 4 |
| ELV | Compliant |
| Body Material | PBT |
| Connector Type | Plug, Socket |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Housing Material | Polybutylene |
| Fastening Type | Latch |
| Circuit Application | Signal |
| Housing Color | Natural |
| Mating Post Length | |
| Mating Tab Width | 1.8 mm |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 2 weeks ago) |
| Polarized | Yes |
| Hybrid Connector | No |
| Termination Post Length |
Stock: 1172
Distributors
pcbx
pcbxUnit Price$0.18158
Ext.Price$0.18158
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.18158 | $0.18158 |
| 10 | $0.15139 | $1.51390 |
| 50 | $0.13515 | $6.75750 |
| 100 | $0.12871 | $12.87100 |
| 500 | $0.11485 | $57.42500 |
| 1000 | $0.10936 | $109.36000 |
